Palladium 25
Portable multi-detection system
Product Description
The Palladium 25 is a next-generation portable multi-detection system designed to locate hidden surveillance devices, whether wireless or wired. Its array of intelligent probes enables professional technical-surveillance countermeasure teams to investigate threats across a broad 10 kHz to 6 GHz range, with optional monitoring up to 12 GHz.
For wireless threats, the intelligent RF probe adjusts automatically and uses omni-directional and optional directional antennas to identify and locate transmitters or transmission links between 10 MHz and 6 GHz, including mobile phones, Wi-Fi, and audio or video devices. Live analysis data can be recorded and archived for the examination of current or historic threats.
The integrated ranging system locates audio transmitters with accuracy to 1 cm. Optical detection reveals hidden cameras even when they are switched off, while visible-light, infrared and laser detectors, together with an ultrasonic probe operating up to 80 kHz, extend coverage to non-RF threats.
For wired threats, the smart cable analyser automatically activates and examines every conductor combination across LAN, RJ45, RJ11 telephone lines and spare cabling. A complementary mains-carrier probe scans line-to-earth, line-to-neutral and earth-to-neutral combinations.
A contact-microphone probe enables operators to listen through walls before entering a potentially hostile environment. The control unit combines a 4.3-inch colour TFT display, audible and vibration alerts, microSD recording, and an internal LiPo battery with USB-C PD charging.
Key Features
- Multi-detection of wireless and wired threats across an overall 10 kHz to 6 GHz frequency range, with optional monitoring up to 12 GHz.
- Detection of encrypted, frequency-hopping and spread-spectrum RF transmitters, with dedicated mobile, 5G and Wi-Fi bands.
- Automatically adjusting intelligent RF probe with omni-directional and optional directional antennas from 10 MHz to 6 GHz; -80 dBm sensitivity for mobile-phone and Wi-Fi signals.
- Audio-transmitter distance measurement with accuracy to 1 cm.
- Hidden-camera optics detection even when switched off, plus infrared, laser, visible-light and ultrasonic transmission detection up to 80 kHz.
- Smart analyser for LAN, RJ11, RJ45 and spare cabling, plus mains-carrier analysis across every conductor combination.
- MicroSD recording and archiving of RF signals and demodulated audio files, with adjustable sensitivity for each band.
- 4.3-inch colour TFT display, audible and vibration alerts, internal LiPo battery, and USB-C PD power and charging.
